In the first example the command displays tdr test results for port 1 slot 1 on device 1 in the stack.

Tdr cable test open.

The time domain reflectometry tdr. The results indicate that the port is down or the cable is not connected. Is it at the closet end or user end. How do i pinpoint at which end the pair is open.

Plug in the connectorized distribution end of any cat 5 utp cable pulled dark and press the analyzer s test button. Tdr test was never run on gi2 12 examples this. Tdr test last run on. Not only is it possible for the time domain reflectometer to discover where the fault or problem has occurred along the cable it is also possible to discover much about the nature of it as well.

It can also be used to locate discontinuities in a connector printed circuit board or any other electrical path. This can be determined by testing a known length of the cable under test and leaving the remote end open. Basic tdr operation application note 58 velocity factor to operate a tdr it is necessary to tell the tdr the speed of the pulse in the cable. Sw 01 test cable diagnostics tdr interface g1 0 5 link state may be affected during tdr test tdr test started on interface gi1 0 5 a tdr test can take a few seconds to run on an interface use show cable diagnostics tdr to read the tdr results.

If the tdr test has not been run on the port the following message is displayed. This arrangement will leave an open condition on the outlet end of each cable. To display the results of the cable analysis enter a command such as the one shown in the following examples at the privileged exec level of the cli. Set up the cable analyzer to test cat 5 utp basic link and select the tdr test mode.

Tdr time domain reflectometer network analysis cable test first line repair handheld cable test fault finders are designed for first line repair and less specialised field operatives where the requirement is accurate and consistent fault location on the most common types of field problems such as open and short circuits. Interface speed local pair pair length remote pair pair status. The pair length can be displayed in meters m centimeters cm or kilometers km. Testing category 5 utp cable.

Different types of cable have different velocity factors vf vf is the ratio of the speed of the cable to the speed of light. This enables the tdr to convert the time the reflected pulses take into distance. A tdr sends a low voltage pulse into the cable under test and at any impedance change within the cable a reflection will be seen. Hence for an open end z z 0 and r is a positive reflection.

It can be used to characterize and locate faults in metallic cables for example twisted pair wire or coaxial cable. Sw despacho 01 show cable diagnostics tdr int g1 0 5 tdr test last run on. In the event of an open or shorted cable the accuracy of length of where the cable is open or shorted is plus or minus 2 meters. Show cable diagnostics tdr int f0 39.
